We are an Authorized JBL Dealer - Full Manufacturer Warranty Included - You will receive:
One (1) NEW & Factory Sealed SRX812 12" 2 Way Speaker - If you need 2 speakers or more, please change the quantity in checkout!
Shipping:
Free Ship via Flat Rate Freight to Physical Street Address in Continental USA - Allow 1-2 Business Days to ship.
Free Ship to Alaska & Hawaii - Allow 5 to 7 business days for delivery.
Overview:
SRX812 is a two-way full range passive portable speaker with a 12†woofer made for use as a light-duty main PA, monitor, or rear or side fill. Featuring M10 suspension points and feet for both floor standing and monitor use, the SRX812 is an ideal solution for musicians, bands, and DJs, concert use, public speaking, or installations such as performance venues, corporate spaces, educational facilities or houses of worship. Tunings and presets are available for Crown ITech HD and XTI 2 amps as well as dbx VENU360 signal processors.
Specifications:
System Type Passive 12, two-way, bass-reflex
Maximum SPL Output 135dB
Frequency Range (-10dB) 41hz - 20khz
Frequency Response (- 3dB) 57hz - 20khz
Sensitivity (1W/1m) 95 dB
System Power Rating 3200W Peak, 1600W Program, 800W Continuous
Nominal Impedance 8 Ohm
Connectors NL4 Input, NL4 Loop-thru (+/-1 or +/-2 Selectable)
Operational Modes Passive/Bi-Amp
LF Driver 2272H
HF Driver 2432H
Coverage Pattern 90° x 50°
Crossover Frequency 1.9khz
Enclosure Material 18mm plywood
Monitor Angle 50°
Suspension/Mounting Dual 36mm pole socket, 12 x M10 Suspension points
Handles 3
Grille Powder coated, Obsidian, 14-gauge perforated steel with acoustically transparent black cloth backing
Dimensions
Length 16.87 in (429 mm)
Width 16.31 in (415 mm)
Height 25.11 in (638 mm)
Weight 55.0 lbs (24.9 kg)
Shipping Weight 65.0 lbs (29.3 kg)
Design
Finish Obsidian DuraFlex finish
Purposeful Design
Every detail in the SRX800 Series was purposefully designed and thought through with full consideration for its intended use. Ergonomically designed handles support an easy, non-fatiguing grip for streamlined handling. M10 suspension points, indexed feet, and pole/tripod mounts support a wide, flexible array of configurations.
Transducer Technology
JBL's patented Differential Drive Technology ferrite drivers incorporate 3" voice coils with lower mass ferrite magnets for reduced weight, increased power handling, exceptionally low distortion and extended low frequency response. JBL's 2432H is the only neodymium 3" voice coil compression drived in this class, delivering very high power levels and smooth, crystal clear sound.
Built to Last
With best in class 18mm wooden enclosures, 14 gauge steel grilles, and JBL's Patented DuraFlex finish, SRX800 speakers are built to last and withstand a lifetime of hard tour use.
