Crown CT475 CommTech Drivecore 4-channel 75W Power Amplifier | 2-Day Ship | NEW Authorized Dealer
Crown CT475 CommTech Drivecore 4-channel 75W Power Amplifier | 2-Day Ship | NEW Authorized Dealer
  • Load image into Gallery viewer, Crown CT475 CommTech Drivecore 4-channel 75W Power Amplifier | 2-Day Ship | NEW Authorized Dealer
  • Load image into Gallery viewer, Crown CT475 CommTech Drivecore 4-channel 75W Power Amplifier | 2-Day Ship | NEW Authorized Dealer

Crown CT475 CommTech Drivecore 4-channel 75W Power Amplifier | 2-Day Ship | NEW Authorized Dealer

Regular price
$1,095.28
Sale price
$1,095.28
Regular price
Sold out
Unit price
per

We are an Authorized Crown Dealer - Full Manufacturer Warranty Included - You will receive:

One (1) New & Factory Sealed Crown ComTech Drivecore CT 475 Four-channel 75W Power Amplifier
Shipping:

Free Shipping via UPS or FedEx 2-Day Air to Physical Street Address in Continental USA, Alaska and Hawaii - Allow One Business Day to ship. If for example: You place your order on Monday, It will ship Tuesday and you will have delivery on Thursday.

Free Ship to Alaska & Hawaii - Allow 5 to 7 business days for delivery.

Overview:
Powering this remarkable amplifier is the pioneering technology of DriveCore, which integrates the amplifier drive stage into the power output stage fusing everything into a chip the size of a dime. DriveCore's front-end drive circuits leverage the inherent efficiency of Class D output stages while also maintaining superb sonic characteristics. The end result is an audio amplifier circuit that exhibits the exemplary audio quality of a highly evolved Class AB design.

Features:

Flexible Input Routing
Convection Cooled
Universal Power Supply
Integrated Life-Safety Features
Up to 8X125W in 1U chassis with no fan
DriveCore technology provides >90% efficiency with no compromise in performance
Patented Feedback and Protection Circuits
Amplifier is stable for 2 16 Ohm Loads
XFMR 4/8 needed for 70V/100V Applications

Specifications:
Channels 4 Sensitivity 1.4 V Rated Power Output (all channels driven) 75W per CH @ 4 ohms, 75W per CH @ 8 ohms Signal to Noise Ratio (below rated power 20 Hz to 20 kHz, A-Weighted) 110 dB THD (full rated power, 20 Hz - 20 kHz) < 0.05% Intermodulation Distortion (from 0 dB down to -30 dB) < 0.05% Frequency Response (at 1W, 4/8 ohms) +/- 0.5 dB Crosstalk (below rated power) 20 Hz to 1 kHz > 70 dB Common Mode Rejection (20 Hz to 1 kHz) > 55 dB, typically > 70 dB Voltage Gain 25 dB DC Offset +/- 20mV
